Instruction
THM-200 vehicle-mounted temperature and humidity sensor is specially designed for demanding industrial applications. It adopts imported humidity measuring elements. It has the characteristics of accurate measurement, wide temperature range, strong resistance to chemical pollution, stable operation and long service life.
The humidity chip used in THM-200 has extremely high temperature tolerance and can work in a high temperature environment of 200°C for a long time. The special treatment of the sensor surface can make the sensor continue to work in a chemically polluted environment. It is the best choice for working in high temperature and harsh environment.
Features

• Used for on-board temperature and humidity measurement of hydrogen energy vehicles
• Signal output: 0.8～4V
• M16 thread for easy installation
• IP65 protection level

Techniacl Paremeter

Model	THM-200
Meauring range	0～100%RH（humidity），-40～200℃（temperature）
Precision	±2%RH（humidity）   ，±0.3℃（temperature）
Repeatability	±0.1%RH（humidity） ，±0.1℃（temperature）
Response time	＜15s
Operating temperature	-40～70℃
Working pressure	＜0.6MPa
Signal output	0.8～4VDC
Power supply	24VDC
Power consumption	＜0.5W
Installation	M16 Threaded installation
